devolo Giga Bridge Coax Starter Kit

Maximum Data Throughput over Coaxial Cabling

• Fiber Optic High Speed to the Destination: The Giga Bridge utilizes existing coaxial cabling as a network line with speeds of up to 1 Gbit/s, effortlessly distributing the internet signal to its destination.
• Clean Installation: No need for complicated cable laying! No risk when drilling, no mess, and no visible cables.
• Easy Setup: The adapters connect automatically, are pre-configured, and thus ready for immediate use – just plug in, connect, and you're done!
• Compatible: All routers/home gateways are supported.
• Thought of Everything: Thanks to the integrated socket with child safety, no power outlet is lost.
• Secure: devolo Giga Bridge adapters communicate only with each other – they are not accessible to unauthorized users from the internet.

Experience the Gigabit speed that your fiber optic connection offers

Fiber optic internet connections are spreading rapidly. However, there is often a challenge: the "long-distance relationship" between the fiber endpoint in the basement and the router in the living area. Laying a LAN or special fiber optic cable is expensive, and placing the router in the basement or utility room is not an alternative. The devolo Giga Bridge offers a simple solution!

The devolo Giga Bridge brings the speed of your fiber optic connection directly to your router. The existing coaxial or telephone line in the house is quickly transformed into a super-fast data highway. For powerful Wi-Fi and perfect wireless telephony throughout the house.

Application 1: ONT – Giga Bridge – Router

Fiber optic high speed to the router – the fiber optic endpoint (ONT) is located in the basement and the router is in the middle of the house.

1. The first Giga Bridge adapter is connected to the ONT via a LAN cable and receives the fiber optic signal.
2. He transmits the fiber optic signal over an existing coaxial cable.
3. The second Giga Bridge adapter receives the fiber optic signal and transmits it to the router via LAN cable.

Result: The gigabit speed of the fiber optic connection is available at the network ports of the router and in the WLAN, with optimal DECT reception ensured.

Application 2: ONT – Router – Giga Bridge

Fiber optic high speed at every coaxial socket – the fiber optic endpoint (ONT) and the router are located in the same room.

1. The first Giga Bridge adapter is connected to the router via a LAN cable and receives the fiber optic signal.
2. He transmits the fiber optic signal over an existing coaxial cable.
3. The additional Giga Bridge adapters receive the fiber optic signal and transmit it via LAN cable to wired devices or access points.

Result: The gigabit speed of fiber optics reaches every room in the house via the coaxial cable.
